Fuente de Poder Variable 30V / 10Amp KPS3010D

Categoría:
Fuentes de Poder fijas y variables
Precio:
Mex$2299.00
{{variant.name}}:
{{opt.name}}
{{opt.value ? '' : opt.name}}
{{opt.value ? '' : opt.name}}
Descripción



Wanptek KPS3010 Precision
Variable Adjustable 0-30V,
0-10A DC Swithing single channel Power Supply
Digital Regulated Laboratory


Feature:

1. Have complete operating protection function
2. Highly efficient, low ripple, small volume, light weight
3. Double display voltage, current, and high precision
4. Voltage stabilization, current limiting, simple operation
5. Dual voltage input and convenient choice
6. Temperature control fan heat dissipation, low noise
7. Double potentiometer more precise adjustment



Specification:

Input voltage:AC 110V/220V,50/60Hz
Output voltage:0 ~ 30V
Output current:0 ~ 10A
Voltage resolution:10/100mV
Current resolution:1/10mA
Power effect:CV=1%+10mV
Effect of load:CV=1%+10mV
Ripple and noise:Vp-p=1%
Voltage display precision:±1%+1digits
Current display precision:±1%+2digits
Net/gross Weight (KG):1.4/1.7
Volume (mm):81W×165H×220L
Operating environment:(-10~45)Rh<90%
Working time:a long time


Package Lists:
1 * Fuente de poder KPS3010D
1 *Cable de alimentacion
1 * Cable para salida
